A revolutionary new joinery system is on the way!  Thermwood is proud to announce our upcoming “Lock Dado” joint.

A Lock Dado joint is an improved version of the old KD joint. It uses a machined dado and tenon to precisely align and securely hold the joint and cam-lock fasteners to clamp it in place.

This new joint can be assembled and disassembled with just a screw driver, yet the joints are rigid, solid and strong.  Combining Lock Dado joints with our patented Assembly Marks makes assembling easy and the joinery strong while allowing for disassembly.

This new joint will be available as a joinery selection in eCabinet Systems in the near future.  Stay tuned for more updates and information.

20 20 Technologies in partnership with Thermwood Corporation, has a special offer available to Thermwood CNC Router Owners:

For a limited time, register for ShopWare CAD training and receive a FREE TRIAL* of ShopWare CAD, the AutoCAD based solid model engineering software from 20-20 Technologies.

Like most other major software packages, ShopWare CAD links seamlessly to your Thermwood CNC Router (enabling you to send your designs straight to the machine).

Please Click Here for More Information

*Sign up now for 2 days of hands-on training and go home with a fully functioning trial version of 20-20 ShopWare CAD.  If you purchase the software before the end of the 90 day period, you will receive a full refund on the cost of training ($550 USD per person)*.

Impact Resistant Head - A positive locating joint between the axis 5 arm and the rest of the machine.  Decreases the amount of force applied to the head in the event of a collision, diminishes the need for realignment and reduces fixture and spindle damage.

Thermwood Continuous C-Axis Rotation with Impact Resistant Head on Model 67 - Video Demonstration

For the first time offered together, the Thermwood Continuous C-Axis Rotation and Impact Resistant Head, demonstrated on a Model 67 5 Axis CNC Router. The Continuous C-Axis allows the machine to perform complex motions that require multiple rotations of the C-Axis, and then quickly return to home. With the Impact Resistant Head, the machine stays in tram even after a crash of the head.

Today is the first day at the WMS show in Toronto where our Canadian Dealer, CNC Automation has a very nice booth with a couple of Thermwood CNC Routers including the New CabinetShop43. We are continualy adding pictures from the show to our TwitPic account. You can view them here:

http://www.twitpic.com/photos/thermwood

You can also follow Thermwood, CNC Automation and the WMS show on our twitter page or blog:

http://www.twitter.com/thermwood

The booth consists of two Thermwood routers, CabinetShop45 and CabinetShop43., and two Fravol Edgebanders, S4 and S7.  They are demonstrating eCabinet Systems and QuickCut on the CS43, cutting random cabinets and 20-20 Technologies is sending files to the CS45.

The CS45 is also creating furniture for Canada's Habitat for Humanity. Once the parts are cut on the machine, they will get edgebanding, finished and assembled right there in the booth, so there are other secondary type of machines within the booth.

 Here are a couple of pics of the CNC Automation /Thermwood booth at the opening of the show:

We've created a couple of videos demonstrating the superior performance of the CabinetShop 43 in a variety of applications.  The first is the Carving of an inset carving, and the second is Cabinet Cutting.

About the CabinetShop 43:  The CabinetShop 43 offers premium performance not normally seen at this price point. For example, it has positioning speeds to 3,180 inches per minute and programmed cutting speeds to 2,250 Inches per minute. The actual speed at which you can cut is determined more by tooling and material than by the machine, but its speed is indicative of the overall solid CNC performance of the CabinetShop 43.

We are pleased to introduce a revolutionary new CNC Router System, called the CabinetShop 43, for nested based applications. This new high performance CNC router is built in the US, at Thermwood's Southern Indiana factory and utilizes a whole new, highly efficient manufacturing approach which results in a superior structure coupled with enhanced use of materials, all at a dramatically lower price.

The new machine features a 61 by 121 inch fixed table, a 10 HP HSD spindle and an eleven position automatic tool changer. It offers high acceleration, high performance motions in both positioning and cutting. This new system includes quality features seldom, if ever, found at this price point including full stress relieved weldments, high-end Siemens drives throughout, THK rails and three-dimensional volumetric position compensation.

The system also includes Thermwood's QCore SuperControl which sharply distinguishes it from every other machine in this class offering features such as:

"QuickCut" is the fastest, simplest, easiest way to make cabinets and closets ever. Just select and resize a cabinet from the library and cut it, all right at the machine control.

"Job Level Interface" means you communicate with every major cabinet design software package using a single job file instead of dozens or hundreds of individual programs. Nesting and program development happen automatically at the machine; an approach that offers dramatically simpler operation and higher productivity.

The QCore SuperControl also executes standard G-Code programs developed elsewhere.

The QCore SuperControl also has an impressive list of operating features all with one purpose, make the machine as foolproof as possible to reduce errors, minimizing the time you fiddle with the machine. It runs more with less effort.

- Automatic Tool Management helps you manage tooling and tracks tool life

- Maintenance Tracking tracks machine use and guides you through routine maintenance

- Graphic Error Reporting shows you exactly where a problem is and suggests solutions

- Complete User Manual in the control

- Dynamic CAD drawings of the entire machine on the control screen

- Maintenance Videos on the control guide you through mechanical adjustments

- Virtual Service provides direct link from the control to Thermwood service

Never before has this level of technical sophistication, quality and performance been available at this price. The CabinetShop 43 is ushering in a new era of productivity, ease of use and profit for custom cabinet operations.

We are pleased to announce a new, simplified approach to nested based production of cabinets and closets that does not require separate cabinet design software. This new approach, called "QuickCut", is done entirely at the CNC machine.

The operator, working at the machine control, simply selects and resizes cabinets and closets from a built-in library and runs them. This entire process happens at the machine. The process is simple enough that virtually anyone can run it with minimal instruction. Libraries can be modified or extended through a programming service.

"For the first time you can operate a CNC router without extensive training or technical skill", says Thermwood's Vice-President of Marketing Jason Susnjara. "This approach allows cabinetmakers to focus on making cabinets using an amazing new tool that's really easy to use".

Operating a CNC router usually requires specialized knowledge which limits its use to specially trained employees. We used the technical power in our Gen2 SuperControl to totally automate virtually every task, then created a simple user interface, resulting in a system that almost anyone can use without extensive training.

The QuickCut feature targets smaller, less technical shops but can also be used by larger companies to make virtually any part or product in their product line any time they want. A library of parts can be stored on a network drive. At that point, almost anyone can walk up to any QuickCut machine and make any part. It's that easy. By storing files in a central location, management has complete control of anything that is made, anywhere in the factory.

"This new interface takes what has been a confusing area for non-technical users and makes it almost as easy as using a copy machine", states Thermwood's President, David Hildenbrand. "We believe it will fundamentally change how cabinets, closets and perhaps many other products, are made".

All nested based systems from Thermwood are QuickCut compatible and Gen2 systems operating in the field can be retrofitted to make them QuickCut compatible.

For more information on this exciting new development, please visit our QuickCut area of the website.

We've just completed updating and expanding our 3 and 5 axis CNC Router areas on thermwood.com.

This new interface allows a wider variety of information to be accessed easily and more quickly than our previous version, and lists images, dimensional drawings (which can be easily printed), technical specifications, movies of the machines in action and brochures all in one convenient place.  I've included some screen shots below - to visit, please click on either:

3 Axis CNC Routers

5 Axis CNC Routers

20-20 Technologies and Thermwood Corporation have joined together to offer a smoothly integrated, highly productive manufacturing system for cabinet manufacturers.

"We are very excited about this new partnership," said Ken Susnjara, CEO of Thermwood.  "This represents a truly comprehensive approach from design and retail all the way through manufacturing, all working together smoothly and seamlessly.  It combines the best technology of both Companies to create an industry-leading offering."

The data process starts with the design.  Over 50,000 dealers use 20-20 Design or ShopWare CAD to layout and sell projects.  To machine a job, an output file from 20-20 software is sent directly to a Thermwood CNC router and the advanced CNC control on the Thermwood system automatically performs all required CAD functions, nests the parts, prints nest diagrams and labels and runs the job directly from full sheets of material.  For even higher production volume, rectangular panels without additional machining are sent to an optimized panel saw, and only parts that require CNC machining are sent to the router.  This not only increases overall production capacity, but represents an increase in productivity as well.

"The advantages to using nested based techniques for machining instead of cutting all panels on a saw and then processing machined parts one at a time on a machining center are significant," said Craig Yamauchi, Executive Vice-President of Manufacturing & Residential Solutions of 20-20 Technologies.  "Labor requirements are less and productivity is higher, sometimes substantially higher."

20-20 welcomes the opportunity to demonstrate the ease of use and high functionality delivered by this partnership for shops seeking best practices and robust integration at this year's AWFS show in July.  20-20 representatives will be on site to show how you can go from the showroom to the shipping dock with greater sales tools, lower costs, fewer errors and increased ROI.

When a customer purchases a Thermwood CNC Router, they become part of our large Thermwood Customer Family. We created this Thermwood Customer Family video to show our appreciation. This video has been updated to show our newest Thermwood Customer Family members with their Thermwood CNC machines in their facilities.
