DXF Buddy is Now Available from CNC Automation

Posted by Jason Susnjara on Mon, Apr 27, 2009

Tags: Thermwood, software, control nesting, CNC Routers, Gen2, CNC Automation, Special, Cad, Layered DXF, super controller, DXF Buddy



 Are you working with Layered DXF files and Control Nesting? Do you run into issues with any of the following?

  • OUTLINE layer depths not matching material thicknesses at the machine...
  • Parts to be machined in "grained" material being drawn in the wrong orientation...
  • You need a left-hand AND right-hand gable but only have the left-hand DXF...
  • The DADO layer is not being recognized because if was incorrectly labeled "DAOD"...
  • You need to flip the back operations to the front and then front operations to the back...
  • No CAD system or CAD operator out at the machine...


DXF Buddy

is here! This small and easy utility will run at the machine and help you rectify all of the issues listed above and then some.

DXF Buddy
is available in two versions - Standard and Pro. The Standard version incorporates a DXF Part Viewer and the ability to manipulate many aspects of the Layered DXF file without the need of accessing a CAD system. The Pro version has all the capabilities of the Standard module and also provide a DXF List Management module that allows you to create a list of DXF parts, set quantities, easily assign materials, mirror/rotate or "pair" individual parts and annotate each entry with a JOB/ASSEMBLY and CAB/SUB-ASSEMBLY designation. The lists DXF Buddy Pro "builds" can then be loaded into Control Nesting in one easy step.

Both versions of DXF Buddy 1.0 have an introductory price of less than $100 CAD!

NOTES:

  • Each license can be installed and run on only one (1) computer. (Software registers to the computer.)
  • All support is done via a email ([email protected]) or on the special forum on the
B2B-Online-Community. No phone support is provided.


Visit the SOFTWARE section of the CNC Automation web store - http://store.cncautomation.com/



Thermwood Links eCabinet Systems to ShopBot

Posted by Jason Susnjara on Wed, Apr 08, 2009

Tags: Thermwood, eCabinet Systems, software, New, CNC Routers, Woodworking, Announcements, Cabinet, Shopbot, cooperative, optimize

Dale, IN April 7, 2009: -- Thermwood Corporation, a leading supplier of CNC routers and founder of eCabinet Systems, the world's largest cooperative of custom cabinet shops, announced the availability of a ShopBot Link that will allow CNC output from its eCabinet Systems software to operate ShopBot CNC routers. The ShopBot Link software program, available from Thermwood, accepts a .twd output file from eCabinet Systems, nests the parts and creates properly formatted files for the ShopBot control.

The new program is the result of a joint effort between Thermwood and ShopBot to expand the use of CNC in the cabinet and custom furniture business. The availability of highly capable but free design software that can output to entry level CNC routers should speed the acceptance of this technology in the marketplace and should ultimately expand the market for everyone.

Thermwood has recently restructured the eCabinet Systems program and added free access to a large collection of cabinet, furniture, closet and carving libraries. These designs, including the carvings, can now be machined on ShopBot CNC routers. For additional information see http://www.ecabinetsystems.com/.

Thermwood Restructures eCabinet Systems Program

Posted by Jason Susnjara on Wed, Apr 08, 2009

Tags: Thermwood, eCabinet Systems, software, CNC Routers, Woodworking, Announcements, Shopbot, cabinets, cooperative, panel saws, tigerstop

Dale, IN April 7, 2009: -- Thermwood Corporation, a leading supplier of CNC routers and founder of eCabinet Systems, the world's largest cooperative of custom cabinet shops, announced that it has restructured the eCabinet Systems program to broaden its appeal and make the software easier to learn.

In addition to continuing to offer the design software free to manufacturers and professional cabinet builders, a major new feature of the restructuring is free access to a collection of cabinet, furniture, closet and carving libraries. " These libraries mean that most users can just download and build without having to first learn the software and create their own libraries", says Thermwood's Vice President of Marketing Jason Susnjara. "We also offer a program to modify these libraries or create all new libraries for individual customers if they want".

For those that want an in-depth understanding of the software Thermwood has developed an extensive web based training program modeled after its successful week long software class. Access to the program is on a subscription basis and Thermwood plans a continuous program of additions and enhancements.

Another major departure from the past is the ability to output code to machines other than Thermwood. Two interface modules have been announced; one to ShopBot CNC routers and one that sends rectangular parts from a job to an optimized panel saw and sends cut-to-length parts to a TigerStop. Thermwood believes these two additions will expand the program by allowing smaller shops to begin using low cost CNC routers and supporting higher volume, panel saw production for larger shops. Thermwood has established an all new eCabinet Systems web site, http://www.ecabinetsystems.com/ to support the restructured program.





New CNC technology handbook Understanding CNC Routers

Posted by Jason Susnjara on Tue, Mar 17, 2009

Tags: Thermwood, software, CNC Routers, tooling, vacuum, manufacturing, Forintek, handbook

Find out how to increase your throughput and improve your bottom line using the latest tools in manufacturing automation.

A taste of CNC technology will change your manufacturing experience forever!

Forintek's new handbook Understanding CNC Routers provides you with an insight on the history of CNC technology as well as with all the information you need about tooling, software, vacuum pumps and the myriad of accessories available to the wood manufacturing industry.

You can order the easy to read 100-page handbook for $20 at [email protected] or contact the author,
Alain Albert directly at 604-222-5613.
