Thermwood has developed our new Five Axis Alignment Verification Routine which is used to record and populate the alignment measurement values into the Thermwood QCore control system (after machine alignments are manually performed).

This routine automatically checks alignment in multiple axes and allows alignment to be quickly verified between jobs.  The routine compares the measured values to the default values.

The Thermwood 5 Axis Alignment Verification Routine includes:

• Renishaw high-tolerance tooling sensor
• Precision ground pin
• Dedicated tool holder
• Collet and all mounting hardware.

For more information on the Five Axis Alignment Verification Routine, please contact us at 1-800-533-6901.

Thermwood would like to invite you to visit us at the JEC Americas Trade Show in Boston, MA.

When:   Wednesday November 7th to Friday November 9th
Where:  Boston Convention and Exhibition Center -Booth #E14

We are exhibiting the latest Thermwood equipment:- Featuring our newest 5 Axis CNC Router - the Thermwood Model 77.

For a limited time, you can receive a FREE Visitor's Badge to attend the show free of charge - act now to take advantage of this offer!

About the Model 77 CNC Machining Center:

The Thermwood Model 77 5x10 (larger sizes are available) is a heavy duty five-axis CNC router specifically developed for three dimensional machining. This stationary table high wall machine was designed using advanced 3D software utilizing Finite Element Analysis. All major welds including the base and gantry are stress relieved to provide long term stability. This machine is inspected and calibrated utilizing a precision volumetric laser system.

Features:
• 12 HP (3,000-24,000 RPM) Spindle
• Impact Resistant 5 Axis Head
• 10 Position Rotary Tool Change System
• Rapid Speed: 3500 inches per minute
• Moving Gantry
• QCore SuperControl
• Siemens Intelligent Servo Drives Throughout
• Volumetric 3D Laser Compensated Axis Alignment
• Automatic Tool Length Sensor
• Machine Training and Installation
• Free Lifetime Phone/Forum Support

More information can be found here

The Thermwood Model 77 5x10 (larger sizes are available) is a heavy duty five-axis CNC router specifically developed for three dimensional machining. This stationary table high wall machine was designed using advanced 3D software utilizing Finite Element Analysis. All major welds including the base and gantry are stress relieved to provide long term stability. This machine is inspected and calibrated utilizing a precision volumetric laser system.

Features:
• 12 HP (3,000-24,000 RPM) Spindle
• Impact Resistant 5 Axis Head
• 10 Position Rotary Tool Change System
• Rapid Speed: 3500 inches per minute
• Moving Gantry
• QCore SuperControl
• Siemens Intelligent Servo Drives Throughout
• Volumetric 3D Laser Compensated Axis Alignment
• Automatic Tool Length Sensor
• Machine Training and Installation
• Free Lifetime Phone/Forum Support

More information can be found here

Carson City, NV: Classic Dash has announced a new molded ABS composite dash panel in three finishes for GM G-body cars, rear-wheel drive iterations that were produced from late '78 until early 1988. These cars include the Buick Regal/Grand National/GNX, Chevrolet Monte Carlo, El Camino, Malibu, GMC Caballero, Oldsmobile Cutlass, Pontiac Gran Prix and Grand Le Mans and Bonneville.

In keeping with all the company's previous offerings, the G-Body panel is clean and stylish. Lightweight and exceedingly rigid ABS plastic sheets are vacuum-formed at 320 degrees Fahrenheit and the material is impregnated with a UV inhibiter that protects it from sun damage. Accuracy is the key. A Thermwood 5-axis CNC high-speed router consistently trims the dash panels to within 0.005-inch.

The Classic Dash panel is available in carbon fiber, brushed aluminum, or black finishes. All panels are offered in two forms: with or without gauge openings, and with or without gauges. Gauge selection includes several variations from Auto Meter and Classic Instruments. Auto Meter kits include wiring harness from gauges to factory loom, LED turn signal indicators, and high-beam and emergency brake light indicators.

Classic Dash was formed in 2002 and was the first company to create replacement ABS composite dash panels for vehicles of the muscle car era. Their new, state-of-the-art manufacturing facility is located in Carson City, Nevada. Its website has a new make-over with easy navigation and access to ordering. Staff members can easily answer any technical questions you may have and same-day shipping is available on orders received before 3PM, PST. Classic Dash instrument panels complete with gauges are priced from $849.95

For further information contact:

Classic Dash, 5225 Grumman Drive, Suite 100,

Carson City, NV 89706

Telephone (866) 882-3525

A & C Products had sent us pictures of their new Thermwood Model 90 nicknamed "The Beast".  They machine a wide variety of materials including REN, Aluminum, Plastics, Copper, Brass and other composites. They also manufacture pleated window shades for private jets.  Below are the pictures of "The Beast"

We are now a Business Member of the American Wind Energy Association (AWEA), and will be exhibiting at the Windpower Expo 2010 in Dallas, TX (May 23rd-26th, 2010).  Make plans now to come out and see us in action.

Thermwood offers 3 and 5 axis systems ideally suited for the production, fabrication and trimming of composites and other materials used in the production of wind energy products.

For more information on our applications in this area, please visit the composite page of our CNC Routers By Applications area.

Here is a reprint from an informative article published in Composites Technology about Bedford Reinforced Plastics and their application of Thermwood CNC Routers in cooling tower fabrication:

Operators of chemical refineries, mining operations and power plants use cooling towers to reduce the temperature of process water that often contains corrosive chemicals. These large square or rectangular structures house equipment in which heated water trickles downward through filtration media while large fans draw air up through the wet media to transfer the heat to the atmosphere. Although cooling towers traditionally have been made with wood and concrete, composite materials are gaining acceptance due to their corrosion and rot resistance, light weight and ease of installation. "Redwood was used in the past because of its innate ability to resist rot. But, as good redwood became scarce, treated Douglas fir was substituted, and in addition to the negatives associated with the chemicals used to treat the wood, fir just couldn't hold up in the cooling tower environment," says Eric Kidd, cooling tower market manager at Bedford Reinforced Plastics (Bedford, Pa.).

Bedford has pultruded square tubes, angles, channels and deck board for cooling tower alternatives since the mid-1990s, says Kidd, including one of the world's largest - a 46-ft tall, 54-ft wide, 1,080-ft long (14.2m by 16.6m by 332m) structure at Barrick Goldstrike Mines Inc. in Carlin, Nev. Bedford supplied more than 600,000 lb (272 metric tonnes) of pultruded components made with Owens Corning Material Solutions' (Toledo, Ohio) continuous filament mat and E-glass roving, Ashland Inc.'s (Columbus, Ohio) fire retardant polyester and vinyl ester resins and polyester surfacing veil. Drilling the thousands of fastener holes and cutouts that enable assembly and fastening of the tower's skeletal structure is a huge challenge. For that task, Bedford employs five 3-axis, CNC-controlled routers from Thermwood Corp. (Dale, Ind.). Configured with overhead moving gantries, the machines have bed sizes that range from 5 ft by 10 ft (1.5m by 3m) to 5 ft by 40 ft (1.5m by 12.2m). According to VP of marketing Jason Susnjara, Thermwood is the only CNC router manufacturer that supplies its own controller programs with the machines, enabling customers to seamlessly integrate CAD/CAM designs with the controller and postprocessor.

Bedford considers automated drilling and cutting to be essential to optimizing finished-part production rates, hole consistency and location accuracy. The former, says Bedford, reduces product lead time, permitting the company to meet tight customer deadlines. The latter ensures that tower structures assemble correctly on site, without delays for part rework.

The NEW Thermwood Online Store now sells collets/covernuts, grease, filters and other accessories for CNC Routers and vacuum pumps.  The Thermwood Store also carries a wide variety of tooling for different industries such as wood, fiberglass, plastics, and composites from different vendors like Vortex, Southeast Tool, CMT and more.  Please visit the Thermwood Online Store to purchase your CNC Router accessories and tooling needs.

Thermwood has added a "CNC Routers by Application" section on their home page.  By selecting the different applications, you can view examples, videos and the machines related to each application.  We will continue to add more pictures and videos to each application.

Featuring the Model 90 - Thermwood machines aren't just for woodworking.  They are also used in a variety of composite, aerospace, trimming, patterns and mold making applications as well as others.  We will be attending the JEC Composites Trade Show on March 24th-26th in Paris, France, and created the following advertisement for that industry:

Check it out:
